SoftScreen® Slant
SoftScreen®️ Slant’s panels and partitions bring to life modern geometric design, calling to mind elegant galas and sophisticated balls. And thanks to the Soft Sound material, you can also achieve targeted sound control, without sacrificing elegant design. Choose from Hanging Bracket, Cable Hung, Sliding Track, and Direct mounting methods to fit the needs of your space.
Key Features
-
Reduce Noise & Enhance Acoustics
SoftScreen®'s Soft Sound® material reduces noise from everyday annoyances like ringing, typing, and chatter resulting in a more pleasant and productive environment. SoftScreen®'s material works in concert with wall coverage or partition capabilities and diffuses sound while enhancing wellness in spaces from busy office environments to soothing waiting rooms.
-
Expansive Soft Sound® Library
Choose from a expanding library of Soft Sound® colors and wood textures. Mix and match colors to accent panels and complement the color scheme of your space.
-
Varying Degrees of Separation
SoftScreen®'s growing collection of solid, half, and full pattern designs create a diverse range of physical separation and visual obstruction to fit the privacy, collaboration, and partition needs of any space.
-
Continuous Aesthetic
SoftScreen's thoughtful design allows for a continuous pattern aesthetic across an array of panels.
-
Height Options
SoftScreen® offers two variable heights to accommodate use in a diverse range of spaces.
-
Diverse Mounting Methods
SoftScreen® attachments are available to create both static and operable panels. Choose from Hanging Bracket, Cable Hung, Sliding Track, or Direct mounting methods to make SoftScreen's various functions a suitable fit for any interior space.
Panel Materials & Colors
Soft Sound® Vivids
Acoustic PET
Soft Sound® Elementals
Acoustic PET
Soft Sound® Wood Textures
Acoustic PET
Soft Sound® Essentials
Acoustic PETHardware Options
Anodized Aluminum
AluminumProduct Details
Pattern Options
Install Option: Direct
Install Option: Cable Hung
Install Option: Hanging Bracket
Install Option: Sliding
Sectional Elevations
Attachment Details
Accessories: Bridge
Accessories: Edge
System Specs
- Dimensions (WxLxD)
- 4´x 8´ x 1/2" (3/4" w/ Channel) Imperial | 122cm x 244cm x 1.3cm (2cm w/ Channel) Metric
- 4´x 9´ x 1/2" (3/4" w/ Channel) Imperial | 122cm x 274cm x 1.3cm (2cm w/ Channel) Metric
- Material
- 12mm Soft Sound® (PET) and Aluminum Track
- Openness
- 23%
- Fire Rating
- ASTM E84 - Class A, UNE-EN 13501-1, B-s1,d0
- Acoustics
- True NRC® 0.35: Wall A Method
- Ceiling/Floor Attachment
- Track or Wire
- Wall Attachment
- Adhesive
- Trimmability
- Yes, per installation manual
Downloads
-
SoftScreen® Slant – Line Brochure PDF – ImperialBrochure5.09 MBpdf
-
Soft Sound® Color Brochure & SpecificationsBrochure681 KBpdf
-
SoftScreen® Slant – 3D DWG – Imperial3D Model14.18 MBzip
-
SoftScreen® Slant – 3D SKP – Imperial3D Model23.02 MBzip
-
SoftScreen® Slant – 3D RFA – Imperial3D Model105.4 MBzip
-
SELECT A STYLE
Select the pattern that best suits your vision and project needs. SoftScreen® is available in a range of styles to fit a multitude of design intents. If a pattern does not meet your intent, custom options are available.
-
SELECT A COLOR
SoftScreen® panels are available in a variety of Soft Sound® colors, including naturalistic Soft Sound® Wood Texture finishes. See our Soft Sound® color brochure for more information.
-
SELECT AN INSTALLATION TYPE
SoftScreen® panels come ready for Direct mount and also offer optional hardware accessory packages. Choose from Hanging Bracket, Cable Hung, and Sliding Track mounting methods.
-
SELECT OPTIONAL ACCESSORIES
Choose from available Edge Guards, Base Guards, and Bridge Brackets, as well as extra Sliding Track.
-
SELECT A NUMBER OF PANELS
All SoftScreen® modules are scalable by design. Select the quantity of modules needed for your project.
Discounts available based on project quantity. Contact your local sales representative for pricing.
Additional options available.
